| Payment Type: | T/T,D/P,Paypal,Others |
| Incoterm: | FOB,CFR,CIF,EXW,DDP |
| Min. Order: | 1 Set/Sets |
| Transportation: | Ocean,Land,Air |
| Port: | SHENZHEN,GUANGZHOU,YIWU |
Share:
Model No.: WD900-2V2F
Brand: WELDO
Origin: DONGGUAN
Certification: CE
| Selling Units | : | Set/Sets |
| Package Type | : | Wooden crate packaging |
| Picture Example | : |
|
The file is encrypted. Please fill in the following information to continue accessing it
| Item | Specification |
|---|---|
| Model | WD900‑2V2F |
| Supported Material | PVC resin, liquid silicone and more |
| Suitable Products | Metal, plastic, wooden stickers, clothing rubber badges, PVC patches |
| Max Color | 6 colors |
| Program Control | Computer installed on machine |
| Vision System | Single vision |
| Camera | 20‑megapixel camera |
| Light Source | Matrix SMD‑LED illumination |
| Vision Scan Size | 400*300 mm |
| Scan Speed | 1‑2 seconds |
| Travel Range | X:980 mm，Y:360 mm，Z:50 mm |
| Working Table | Single working table |
| Table Size | 400*300 mm |
| Max Working Speed | 60000 mm/min |
| Dispensing System | Precision Spray Valve System |
| Fastest Dispensing Speed | 5 ms |
| Machine Positioning Accuracy | ±0.05 mm |
| Camera Positioning Accuracy | ±0.2 mm |
| Dispensing Accuracy | 0.001 ml |
| Drive System | Screw ball + AC servo motor |
| Pneumatic Part | Precision pressure regulating valve |
| Max Table Load | 50 KG |
| Working Voltage | 220V 50HZ |
| Power | 3000W |
| Machine Dimension | 1500(L)*1740(W)*1915(H) mm |
| Net Weight | 850 KG |
| Gross Weight | 920 KG |
| Export Packing | Plywood wooden case |
| Packing Size | 1550(L)*1330(W)*2060(H) cm |
| Volume(CBM) | 4.2 |
WELDO was founded in 2007 and relocated in 2010 to Dongguan, a city renowned as the “World’s Factory.” As a national high-tech enterprise, the company boasts a highly qualified team — over 50% of... Subscribe Our Newsletter
